Printed Circuit Board Fabrication Description:
PCB products not only facilitate the standardized assembly of various components but also enable automated and large-scale mass production. In addition, the overall assembly of the PCB and various other components can also form larger components, systems, and even complete machines.
Since the components of PCB products and various components are assembled in a standardized design and large-scale production, these components are also standardized. Therefore, once the system fails, it can be replaced quickly, conveniently, and flexibly, and the work of the system can be quickly restored.
Printed Circuit Board Fabrication Parameters:
| Item | Technical Parameter |
| Layer | 2-64 |
| Thickness | 0.3-6.5mm |
| Copper Thickness | 0.3-12 oz |
| Min Mechanical Hole | 0.1mm |
| Min Laser Hole | 0.075mm |
| HDI | 1+n+1,2+n+2,3+n+3 |
| Max Aspect Ratio | 20:01 |
| Max Board Size | 650mm*1130mm |
| Min Width/Space | 2.4/2.4mil |
| Min Outline Tolerance | ±0.1mm |
| Impedance Tolerance | ±5% |
| Min PP Thickness | 0.06mm |
| Bow &Twist | ≤0.5% |
| Materials | FR4, High-Tg FR4, Rogers, Nelco, RCC, PTFE, M4, M6, TU862, TU872 |
| Surface Finished | HASL, HASL Pb Free Immersion Gold/Tin/Silver Osp, Immersion Gold+OSP |
| Special Capability | Gold Finger Plating, Peelable, Carbon ink |
FAQ:
Q. What is your Minimum Order Quantity (MOQ)?
There is no limit to our MOQ, depending on the specific requirements, samples and mass production can be supported, and customized models are supported.
Q: Do you have MOQ restrictions?
We do not have any limit on order quantity and can support samples and mass production. The specific situation depends on the needs of customers and can be communicated with the staff.
Printed Circuit Board Fabrication Introduction:
The printed circuit board has good product consistency, and it can adopt a standardized design, which is conducive to the realization of mechanization and automation in the production process. At the same time, the entire printed circuit board that has been assembled and debugged can be used as an independent spare part, which is convenient for the exchange and maintenance of the whole product. At present, printed circuit boards have been widely used in the manufacture of electronic products.
